To satisfy strict industry standards for automation products, particularly products designed for packaging, label slitting,
and motion-based robotic dispensing applications, Advantech developed a series of RISC-based operator panels,
available in sizes ranging from 4.3" to 10.1".
The WOP-2000T series equipped with a real-time OS and WebAccess/HMI |
|
| |
|
|
|
 |
|
| |
 |
 |
|
| |
| Packaging |
 |
|
|
| Label Sitting |
 |
|
|
| Robotics Dispensing |
 |
|
|
 |
|
|
 |
 |
 |
 |
 |
| Datasheet |
 |
|
|
|
|
| Model Name |
WOP-2040T |
WOP-2050T |
WOP-2070T |
WOP-2080T |
WOP-2100T |
| Part Number |
WOP-2040T-S1AE
WOP-2040T-N1AE |
WOP-2050T-S1AE |
WOP-2070T-S2AE
WOP-2070T-N2AE |
WOP-2080T-S2AE
WOP-2080T-N2AE |
WOP-2100T-S2AE
WOP-2100T-N2AE |
| Display Size |
4.3" |
5.6" |
7" |
8" |
10.1" |
| Touch type |
WQVGA (16:9) TFT LCD |
QVGA TFT LCD |
WVGA (16:9) TFT LCD |
SVGA TFT LCD |
WSVGA TFT LCD |
| Resolution Max. |
480 x 272 |
320 x 234 |
800 x 480 |
800 x 600 |
1024 x 600 |
| Luminance |
400 cd/m2 |
330 cd/m2 |
300 cd/m2 |
250 cd/m2 |
250 cd/m2 |
| Weight |
0.3 kg |
0.51 kg |
0.6 kg |
0.93 kg |
1.2 kg |
| Viewing Angle |
100°/95° |
130°/110° |
140°/130° |
140°/130° |
140°/110° |
| Backlight Lifetime |
20,000 hrs |
20,000 hrs |
20,000 hrs |
30,000 hrs |
20,000 hrs |
| Dimensions (W x H x D) in mm |
130 x 106.2 x 36.4 |
188 x 143.3 x 30 |
188 x 143.3 x 30 |
231.5 x 174.6 x 37 |
269.8 x 212 x 37.4 |
|
| |
|
|
 |
|
|
